STATIC/DYNAMIC Input Range, °: ±3 ±14.5 ±30 ±45 ±60 ±90 Full Range Output (FRO -Note 1) VDC ±0.5%: 0-5 0-5 0-5 0-5 0-5 0-5 Nonlinearity (Note 2) % FRO maximum: 0.05 0.02 0.02 0.02 0.04 0.05 Scale Factor, Volts/g, nominal: 47.8 10.0 5.0 3.5 2.9 2.5 Scale Factor Temp. Sensitivity (SFTS), PPM /°C maximum: 100 100 100 100 100 100 Bandwidth (-3 dB), Hz nominal: 5.0 5.0 5.0 5.0 5.0 5.0 Output Axis Misalignment, ° maximum: 0.25 0.50 0.50 0.50 0.50 0.50 Pendulous Axis Misalignment, ° maximum: 0.25 0.50 0.50 0.50 0.50 0.50 0° Output, Volts range: 0° Output Temp. Sensitivity, Volts /°C maximum: 0.0036 0.0010 0.0007 0.0005 0.0005 0.0005 Resolution and Threshold, μradians maximum: 3.5 3.5 3.5 3.5 3.5 3.5 ELECTRICAL ENCLOSURE Number of Axes: 1 Seal: IP65 Input Voltage Range, (VDC): +15 to +30 Input Current, mA, max: 40 Output Impedance, Ohms, nom: 10 Noise, Vrms, maximum: 0.002 ENVIRONMENTAL Operating Temp Range: Storage Temp Range: Shock: Notes: Note 1: Full Range is defined "from negative full input angle to positive full input angle." Custom Capabilities ? ±15V bipolar input option available Connector Version Pin Version ? Pigtail and Connector alternative Model # Part # Model # Part # options available SMIC-S-3 02550304-001 SMIP-S-3 02550303-001 ? Custom ranges and bandwidths SMIC-S-14.5 02550304-002 SMIP-S-14.5 02550303-002 available SMIC-S-30 02550304-003 SMIP-S-30 02550303-003 SMIC-S-45 02550304-004 SMIP-S-45 02550303-004 SMIC-S-60 02550304-005 SMIP-S-60 02550303-005 SMIC-S-90 02550304-006 SMIP-S-90 02550303-006
